Shoulder Support

The Shoulder Support is manufactured from high grade stainless steel and the pads are a mixture of firm foam at the base and memory foam on top, minimising the risk of nerve damage.

TT/101 Shoulder Support Complete with Pads
TT/102 Shoulder Support Replacement Pads (Pair)

Metalwork:  Medical grade 306 stainless steel.

Pads:  Inner high resilient foam which has a firm base and Visco (memory foam top) covered in multi-stretch, waterproof polyurethane covering.

Fire Specification: Crib 5, Ignition source 0 to BS7177

Cleaning: 1,000 ppm diluted or 0.1% hypochlorite solution (to be used in conjunction with local infection control guidelines).

Chose the appropriate table clamp that will fit the operating accessory rail, slide on the rail.

Position the clamp on the rail in accordance of the where the Shoulder Support should be positioned, which is the head end of the patient whereby their shoulders will be placed.

Slot the flat upright bar of the Shoulder Support into the clamp and tighten enough so that the support stays in place under pressure. (do not over-tightened as the inner thread in the clamp can be damaged).

The Shoulder Support is now ready to use.
